Product Summary

100V 76V 60 kWh EV Car Battery Pack Van LiFePO4 Battery Energy Storage Rechargeable Battery Rated capacity (Ah) 177 177 Nominal Voltage (V) 102.4 76.8 system grouping 3P32S 3P24S Rated storage power (Wh) 18583 13593 System energy density (Wh/kg) 139.3 137.96 Operating temperature range (℃) Charge:0~60 discharge:-20~60 Charge:0~60 discharge:-20~60 System weight (kg) 133±5 97±5 Maximum continuous charge rate ( 10℃~40℃, 5% 0.75C 0.75C Maximum continuous discharge rate (10℃~45℃,

100V 76V 60kWh EV Car Battery Pack , Van Energy Storage Rechargeable LiFePO4 Battery

Basic Properties

Place of Origin: China
Brand Name: HUAXIN
Certification: MSDS,CE,KC, BIC
Model Number: B3303

Trading Properties

Minimum Order Quantity: 1
Price: can be negotiated
Standard Packaging: can be negotiated
Delivery Time: 10 work day
Payment Terms: T/T
Supply Ability: 99999pcs/months
Product Details
Highlight:

100V EV Car Battery Pack

,

60kWh Rechargeable LiFePO4 Battery

,

Van Rechargeable LiFePO4 Battery

Discharge End-Off Voltage: 8.8-10V
Charge Voltage: 14.4V -14.6V
Capcity: 100Ah (1280Wh)
BMS System: Smart BMS With High/low Voltage, Temperature ,short Circuit Protection. Charging Full Time
Charging Full Time: About 6hours (@0.2C)
IP Protection Class: IP67
Product Description
Detailed Specifications & Features

100V 76V 60 kWh EV Car Battery Pack Van LiFePO4 Battery Energy Storage Rechargeable Battery



Rated capacity (Ah)
177
177
Nominal Voltage (V)
102.4
76.8
system grouping
3P32S
3P24S
Rated storage power (Wh)
18583
13593
System energy density (Wh/kg)
139.3
137.96
Operating temperature range (℃)
Charge:0~60 discharge:-20~60
Charge:0~60 discharge:-20~60
System weight (kg)
133±5
97±5
Maximum continuous charge rate
( 10℃~40℃, 5%
0.75C
0.75C
Maximum continuous discharge rate
(10℃~45℃, SOC>30% )
1C
1C
Self-discharge rate/month (25℃,SOC100%)
<5%
<5%
IP Protection class
IP67
IP67
Factory battery packSOC
50%
50%
Battery pack SOC working range
15~100%
15~100%
Capacity Attenuation (EOL) During the Warranty Period of the Battery Pack
Typical value⩽ 20%
Typical value⩽ 20%
Anti-vibration performance
Meet GB38031-2020 standard
Meet GB38031-2020 standard
Insulation requirements
≥20MΩ
≥20MΩ
Dimensions (mm)
1225*420*197
1225*420*197



Features of ELECTRIC CAR battery pack:

1. Lighter weight, smaller size.
2. High-temperature performance.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Maintenance-free and no acid or water for maintenance in usage.
7. Large capability and long life for all high-power output applications.
8. Environmentally friendly non-toxic, non-contaminating, no rare metal.
9. Low self-discharge and good discharge performance at low temperatures.
10. Excellent large current discharge performance especially in startup and climbing.
